Processor
Marvell OCTEON TX2™ CN9130/CN9131 ARMv8 Cortex-A72 4-core 2.2GHz Processor
CPU Architecture
64-bit ARM
Floating Point Module
Yes
Encryption mechanism
Yes
System memory
4 GB SODIMM DDR4 (1 x 4 GB)
Maximum memory
32 GB (1 x 32 GB)
Memory slot
1 x SODIMM DDR4
Flash memory
4 GB (dual-boot OS protection)
Drive Bay
4 3.5-inch SATA ports, 6 Gbit/s, 3 Gbit/s
Drive compatibility
3.5-inch bays:
3.5-inch SATA hard drives
2.5-inch SATA solid-state drives
Hot-swappable
Yes
M.2 Slot
2 slots M.2 2280 PCIe Gen 3 x1
SSD Cache Acceleration Support
Yes
2.5-Gigabit Ethernet Port (2.5G/1G/100M)
2 (2.5G/1G/100M)
10-Gigabit Ethernet port
2 10GbE SFP+ ports
Wake Up over LAN (WOL)
Yes
Jumbo Frame
Yes
USB 2.0 port
2
1st generation USB 3.2 port
2
Form Factor
Installation in a rack of shallow depth 1U
LED indicators
Hard disk 1-4, Status, LAN, USB, M.2 solid-state drive 1-2
Buttons
Power, Reset
Dimensions (HxWxD)
43.3 × 430 × 292.12 mm
Net weight
4.17 kg
Operating Temperature
0–40 °C (32–104 °F)
Storage temperature
-20–70°C (-4–158°F)
Relative humidity
Relative humidity 5-95%, non-condensing, according to wet thermometer: 27°C (80.6°F)
Power unit
Power supply 100 W, 100-240 V
Power Consumption:
Hard disk Sleep mode 17.367 W
Power consumption:
Operating mode, typical 30,878 W
Fan
3 x 40 mm, DC 12V
System warning
Buzzer
Kensington Security Slot
Yes
Max. Number of simultaneous connections (CIFS) – with max. Memory
1500
